procreate colordrop not filling whole area
HeyBraza points at the colordrop threshold slider - the hold-and-drag gesture nobody discovers - so your fill stops leaking or under-filling.
you drag a color onto a shape and it either floods the whole canvas or barely fills anything. the cause is almost always the colordrop threshold, set by a gesture procreate never tells you about. here's how to control it on your ipad.
short answer
drag the colour swatch onto the area but don't lift your finger - a threshold bar appears at the top, and sliding right fills more. if it floods the whole canvas, your outline has a gap: close it, or set the line-art layer as a 'reference' layer and fill on a layer above.
or do it yourself
- 1pick your color, then drag the color swatch from the top-right onto the area you want to fill.
- 2don't lift your finger - keep holding, and a 'colordrop threshold' bar appears across the top.
- 3slide your finger right to raise the threshold (fills more) or left to lower it (fills less), then release when the fill looks right.
- 4if it floods the whole canvas, your shape has a gap in its outline - close the line, or set the line-art layer as a 'reference' layer and fill on a layer above it.
- 5zoom in to spot tiny gaps where color is escaping and patch them before filling again.
steps last checked
let HeyBraza do this with you
HeyBraza teaches you software while you're using it. hold a key and ask out loud - an ai tutor that sees your screen walks you through every step in real time, pointing and highlighting on your real work, talking you through it as it goes - not someone else's tutorial.
downloadcommon questions
why does colordrop fill my whole screen?
the outline has a gap so the fill escapes - close the gap, or set your line layer as a reference layer and colordrop on a separate layer above it.
where is the colordrop threshold in procreate?
there's no button - drag the color onto the canvas and keep holding; the threshold slider appears at the top while your finger is down.
