blender bevel not working
HeyBraza points at ctrl+a apply scale, then at clamp overlap and segments so the bevel comes out even.
an uneven or missing bevel is almost never the bevel tool. if your object has been scaled in object mode, blender bevels in the scaled space - so one side comes out fatter. applying the scale fixes most cases instantly.
short answer
apply scale first with ctrl+a - an unapplied scale is the single most common reason a bevel does nothing visible. after that, merge doubled vertices and try unticking 'clamp overlap', which silently limits the bevel wherever geometry is tight.
or do it yourself
- 1in object mode select the object and press ctrl + a > 'scale' - check the n-panel now reads scale 1, 1, 1.
- 2enter edit mode, select all (a), and press m > 'merge by distance' to delete doubled vertices sitting on your edges.
- 3add the bevel: modifier properties > 'add modifier' > 'generate' > 'bevel', then raise 'amount' above zero.
- 4if it still looks flat, untick 'clamp overlap' - it silently limits the bevel wherever geometry is tight.
- 5raise 'segments' to 2-3 for a rounded edge, and set 'limit method' to 'angle' so flat faces aren't bevelled.
steps last checked
let HeyBraza do this with you
HeyBraza teaches you software while you're using it. hold a key and ask out loud - an ai tutor that sees your screen walks you through every step in real time, pointing and highlighting on your real work, talking you through it as it goes - not someone else's tutorial.
downloadcommon questions
why is my bevel bigger on one side?
non-uniform scale. ctrl + a > scale in object mode, then bevel again.
bevel works in the modifier but not with ctrl + b - why?
ctrl + b is the edit-mode tool and needs edges selected; scroll the mouse wheel while dragging to add segments.
why does bevel not work in blender even with the modifier added?
an unapplied object scale is the usual answer - press ctrl+a > scale in object mode and check the n-panel reads 1, 1, 1. after that, doubled vertices and 'clamp overlap' are the next two suspects.
